Heckler & Koch · Sniper Rifle
Heckler & Koch G28
Gas operated short stroke piston · 7.62x51mm NATO · introduced 2012
Also known as G28, M110A1, CSASS
About the Heckler & Koch G28
The Heckler & Koch G28 is a designated marksman rifle adopted by the German Bundeswehr in 2012, based on the HK417 battle rifle platform. Featuring a free-floating barrel, short-stroke gas piston system, and match-grade two-stage trigger, the G28 provides sub-MOA accuracy in a semi-automatic platform that allows rapid follow-up shots. The rifle was selected by the United States military as the M110A1 Compact Semi-Automatic Sniper System (CSASS), replacing the Knight's Armament M110 SASS.
The G28's selection as the US military's M110A1 CSASS marked the first time a German-designed semi-automatic precision rifle was adopted as a standard-issue American military weapon. The rifle beat out several American competitors, a testament to HK's engineering of the short-stroke piston system that delivers both precision accuracy and the legendary HK reliability in adverse conditions.
Heckler & Koch G28 specifications
General
- Type
- Sniper Rifle
- Action
- Gas operated short stroke piston
- Firing mechanism
- Hammer-fired
- Trigger
- Two stage
- Trigger pull
- 2.0 kg (4.5 lb)
- Calibres
- 7.62x51mm NATO
- Magazine capacity
- 20 rounds
- Magazine
- Detachable box magazine
Dimensions
- Barrel length
- 420 mm (16.5 in)
- Overall length
- 1025 mm (40.4 in)
- Weight (empty)
- 5.50 kg (12.13 lb)
- Weight (loaded)
- 6.20 kg (13.67 lb)
Barrel
- Rifling twist
- 1:11 in (280 mm)
- Rifling
- Right hand
- Grooves
- 4
Materials
- Barrel
- Steel
- Receiver / frame
- Aluminum alloy
- Stock
- Polymer adjustable
- Finish
- tan_cerakote
Performance
- Muzzle velocity (typical)
- 780 m/s (2559 fps)
- Muzzle energy (typical)
- 2890 J (2132 ft·lb)
- Effective range
- 800 m
History
- Introduced
- 2012
- Production status
- In production
- Country of origin
- DE
Features
- Free floating barrel
- Picatinny quad rail
- Adjustable gas regulator
- Suppressor ready
- Adjustable buttstock
- Adjustable cheek piece
- Ambidextrous controls
- Hk proprietary upper receiver
Safety
- Ambidextrous safety
- Firing pin safety
The G28 is derived from the HK417 but with significant modifications for the precision shooting role including a match barrel, improved trigger, and enhanced optics mounting system. The Bundeswehr procured the G28 in two configurations: the Patrol variant with a shorter barrel for general use, and the Standard variant with a longer barrel optimized for precision shooting. The US M110A1 CSASS variant is chambered in 7.62 NATO and uses a 16.5-inch barrel, slightly shorter than the German standard variant. The G28's short-stroke gas piston system provides excellent reliability while keeping the action cleaner than direct-impingement systems.
