Lee Navy M1895

Name: Lee Navy M1895
Brand: Winchester

Straight-pull bolt · 6mm Lee Navy · introduced 1895

Also known as Winchester-Lee, Lee Model 1895 Navy, .236 Navy

Find Winchester Lee Navy M1895 for sale Check the market price

About the Lee Navy M1895

The Lee Navy M1895 (Winchester-Lee) was a straight-pull bolt-action rifle designed by James Paris Lee and manufactured by Winchester Repeating Arms for the United States Navy and Marine Corps. It fired the small-bore, high-velocity 6mm Lee Navy smokeless cartridge, the first such round adopted by a US service, fed from a 5-round en bloc clip into an internal box magazine. Its flat trajectory gave an excellent battle-sight zero.

US Marines carried the 6mm Lee Navy in the defense of the Peking legations during the Boxer Rebellion, where future Medal of Honor legends Smedley Butler and Dan Daly fought, making this short-lived straight-pull one of the earliest small-bore smokeless rifles to see American combat.

Lee Navy M1895 specifications

General

Type: Rifle
Action: Straight-pull bolt
Firing mechanism: Striker-fired
Trigger: Single stage
Calibres: 6mm Lee Navy
Magazine capacity: 5 rounds
Magazine: En bloc clip

Dimensions

Barrel length: 711 mm (28.0 in)
Overall length: 1213 mm (47.8 in)
Weight (empty): 3.77 kg (8.31 lb)

Barrel

Rifling: Right hand

Materials

Barrel: Steel
Receiver / frame: Steel
Stock: Wood
Finish: blued

Performance

Muzzle velocity (typical): 779 m/s (2556 fps)
Effective range: 549 m

History

Introduced: 1895
Discontinued: 1907
Production status: Out of production
Country of origin: US
Designer: James Paris Lee

Features

Straight pull bolt
En bloc clip feed
Small bore high velocity
Smokeless powder

Safety

Manual safety

The straight-pull action's floating extractor proved fragile in service, and the rifle was withdrawn in favour of the Krag–Jørgensen and later the M1903 Springfield. Surviving examples are prized by collectors but the obsolete 6mm cartridge is difficult to source.
